RodTite Rod Holder Instructions:
Fits any ½”–13nc base (not included)
Assemble with ½” SS stem bolt (standard 4” long) through slot with head inside rod holder body, add SS flat washer and top SS wing nut with flat up toward rod holder body then add bottom SS standard nut, install stem in base, adjust, tighten and go fishing.
Adjust vertical tilt by loosening upper flange nut, tilt in slot to desired angle then tighten flange nut.
Adjust Horizontal direction by loosening lower nut, rotate to desired angle and tighten nut.
For large bait casting reels, locate reel toward back of rod holder to prevent damage to level wind.
For best results when trolling more than 1 mph adjust horizontal direction from straight back to about 45 degrees and vertical tilt substantially above horizontal.
For easy rod removal the minimum mounting height above any flat deck should be greater than your rod butt length. 6” stem bolts and T-Bars are available as an option or accessory.
A 3/4" wrench or adjustable wrench (not included) is needed for tightening and adjustments
